Side-Sealing Bag Making Machine

26 inches 30 inches 40 inches etc.
Application:
ls used in maxing BOPP,OPP.PP,POF,PE side seaing bag.

Consult

Features Technical Indicators Overall Dimension

(1)lncluded break edge,folding bottom,on tape,punching,hot sealing & hot cutting function.
(2)Unwinder with EPC,servo system,inverter for speed regulation,computer control and auto count technical.
(3)The hot sealing blade can make dentation seal or straight seal,near this sealing blade is a water cooling device.

Main Technical Parameters
Model	HWBR-20°	HWBR-26°	HWOR-30°	HWR-40°
Mox.cuting holaih(mm)	480	620	720	900
Max.cutling widih(mm)	800	1000	1000	1000
Thicknesp ot culting	0.008-0.2	0.008-0.2	0.008-0.2	0.008.02
Error rango(mm)	≤±0.5	≤±0.5	≤±0.5	≤±0.5
Outout(pcs/min)	20-150	20-150	20-150	20-150
Hoaling powor(kw)	2.2	2.4	3	3.6
Totalpower(kw)	3.9	4.1	4.6	6.5
Weigh(kg)	650	850	900	1050
Dimonsion(mm)	3800x1150x2000	4200x1250x2000	4200x1450x2000	4500x750x2000
